; Demonstration of Microchip 16C84 for BATC. ; Brian Kelly. 14th February 1997 ; The next line tells the assembler which type of PIC is being used, the ; default radix (number base) to use unless told otherwise and how many ; columns to use in the program listing before wrapping text to the next line. list p=16C84, r=HEX, c=132 ; Define the values to be associated with the register names and bit names ; used later in the program. Whenever one of the names on the left of 'equ' ; is encountered, the assembler substitutes the value on the right. This is ; not essential as the values themselves could be used but using meaningful ; names makes the program far easier to read and understand. Capital letters ; have been used for pre-defined registers, the remainder are used to store ; variables used in the program. RTCC equ 01 ;the real time clock/counter register STATUS equ 03 ;various status and control bits PORT_B equ 06 ;port B, where the LEDs are connected INTCON equ 0B ;bits for configuring the interrupts OPT_REG equ 01 ;processor options (in register bank 1) TRIS_B equ 06 ;port B pin direction controls (in bank 1) pattern equ 0C ;the on/off pattern of the LEDS direction equ 0D ;only bit 0 used to decide left/right same equ 1 ;put result back where in the source register w equ 0 ;put result back in the working (W) register C equ 0 ;bit number of the carry flag in STATUS ; The program counter (PCL), points to the next instruction to read and is ; set to 000H on reset so the first instruction to be executed must be there. ; As the interrupt vector is at address 004H, not leaving much space for code, ; we will start the program with a jump to an area where there is more space. init org 000 ;tell assembler to start at 000 goto start ;the jump mentioned above. ; This is the interrupt routine. A jump to address 004 occurs whenever an ; interrupt is generated. In this 84DEMO program, all the interrupts are ; disabled except for the one caused by the RTCC overflowing (reaching maximum ; count of FFH and rolling over to zero). demo org 004 ;move assembler to the interrupt vector bcf INTCON,2 ;clear the interrupt bit so the chip ;doesn't immediately generate a new one ;when interrupts are turned back on. ;as this point is reached at fixed time ;intervals, use it to switch LEDs display movf pattern,w ;use working register to carry pattern movwf PORT_B ;to port B btfss direction,0 ;check which direction to shift. ;skip next instruction if going right goto left ;the left shift routine right bcf STATUS,C ;ensure carry=0 before shifting rrf pattern,same ;shift the pattern one position right btfsc pattern,0 ;skip next inst if not fully at right bcf direction,0 ;fully right so reverse direction retfie ;return from interrupt to main program left bcf STATUS,C ;ensure carry=0 before shifting rlf pattern,same ;shift the pattern one position left btfsc pattern,7 ;skip next inst if not fully at left bsf direction,0 ;fully left so reverse direction retfie ;return from interrupt to main program ; This is the part of the program entered when powered up or reset. It ; initialises the processor and puts starting values in some registers. After ; setting everything up it goes into a loop, waiting for interrupts to occur. start movlw B'00100000' ;select register page 1 movwf STATUS clrf TRIS_B ;set all port B pins to output mode movlw B'10000111' movwf OPT_REG ;sets: pull-up on port B OFF ; RTCC counts internal clock ; prescaler connected to RTCC ; prescaler divides by 256 ; (other bits unimportant) ; change the "111" to alter sweep speed. clrw ;clear the working register movwf STATUS ;switch back to register page 0 movwf direction ;set direction to LEFT (bit 0 = 0) movlw B'00000001' ;starting pattern for LEDS movwf pattern movlw B'10100000' movwf INTCON ;sets: global interrupts enabled ; RTIE enabled (RTCC roll over) ; (other bits disabled/cleared) loop goto loop ;wait here for interrupts. end ;tell assembler there's no more
